Brighton LED Trunk Linear System:T8 Light Module
Overview
The Brighton LED Trunk Linear System: T8 Light Module is a rather superior lighting device, gradually replacing traditional incandescent and energy-saving lamps, and is increasingly loved by users. Our lights have three colors of light arbitrarily adjustable, easy to use. Its wattage can also be adjusted. Our lights are made of fine materials, wear-resistant and durable. The general life of our Brighton LED Trunk Linear System: T8 Light Module can last 30,000 hours.
Features
Compared with other similar products, our Brighton LED Trunk Linear System: T8 Light Module has many advantages, such as stable performance and reasonable price, etc. Our LED lights are cold light sources, with little glare, no radiation and no harmful substances in use. In addition, its low operating voltage, DC drive mode, ultra-low power consumption, electro-optical power conversion close to 100%, in the same lighting effect than the traditional light source energy saving more than 80%.
|
 |
Details Various module Tool-Free installation Max 200 meters multiple link 3-phase AC power source 5/7/11 wiring system Tri-color :3000/5000 mixed 4000K Various function : 1-10V /DALI / Micro-wave sensor / PIR sensor / 3H emergency Options: ·Functions : ON-OFF / 1-10V dimming / Micro-wave sensor / PIR Sensor / 3H EM @10% Lumen output · Lighting color: Single color or Tri-color · Beam Angle: 120 Degree · Installation: Surface mounting OR Suspension |
| Application |
Commercial lighting applications : Supermarkets, Shopping malls, Airports, Stations, Cap parks, etc. Office lighting applications : Offices , Conference rooms, Showrooms, Classrooms, libraries, etc. Industrial lighting applications Factories, Warehouses, Workshops |
|
| ·Explosion drawing |
 |
| ·Trunking Rail |
BRIGHTON trunk rails are the pre wiring part, which provides AC power supply and control signal module. The main girder has 5 / 7 / 11 line type, which can meet the requirements of different modules. There are 0.6m, 1.5m, 2.4m and 3.0m. The node connector with wired Wago terminals on both sides of the main rail can not only make the tools free of charge, but also determine the installation direction. |
|
| ·Explosion drawing |
BRIGHTON trunk linear system provides a very professional cabling system. The main line is 5 / 7 / 11. Wago connector used in Brighton trunk line not only uses a three-phase 2.5m (20awg) power line but also uses a Wago phase conversion function connector. It allows up to 16a and 200m main rails to be connected in a 3-phase power supply system.
|
| ·Start Unit |
The Brighton start-up unit enables the trunk linear system to connect each loop with only one AC power supply. It can be inserted at the beginning or at the beginning The starting unit has a female Wago AC connection terminal, which can be easily inserted into the main line track to complete the installation. It provides 5 / 7 / 11 wires |
|
| ·Start Unit |
|
|
Micro-wave sensor module
|
PIR sensor module
|
Emergency module
|
Track Rail
|
Blank Cover
|
| Accessories |
 |
