• Features
> Aluminum round shape + Prismatic diffuser UGR<19
> Juntion box for easy installation > Various of function options
> Warranty: 5 years
• Options
> F1: ON-OFF
> F2: Emergency
> F3: Microwave Sensor
> F4: Microwave Sensor+Emergency > F5: Self-Test Emergency
> F6: Self-Test Emergency+Microwave Sensor
• Applications
Replacement for 2D fluorescent
Stairs / corridors Homes and houses
|
Item |
Symbol |
D450 |
D350 |
D600 |
D900 |
|
Vasco Ceiling D450 |
Vasco Ceiling D350 |
Vacso Ceiling D600 |
Vasco Ceiling D900 |
||
|
Rated Power |
W |
26W Multi-current |
22W Multi-current |
50W Multi-current |
68W Multi-current |
|
Product Code |
/ |
BH45-20KN1-CPFXE-001 BH45-30KN1-CPFXE-001 |
BH35-20KN1-CPFXE-001 BH35-30KN1-CPFXE-001 |
BH60-50KN1-CPF01 |
BH90-68KN1-CPF01 |
|
LED Type/Qty |
SMD2835 |
208x2 |
156x2 |
208x2 |
156x2 |
|
Lumen Efficacy |
Lm/w |
typ.120±10% |
typ.120±10% |
typ.120±10% |
typ.120±10% |
|
Luminous Flux LM typ.2808 typ.2376 typ.5400 typ.7344 |
|||||
• ErP Technical Specification
|
Item |
Specification / Data |
Item |
Specification / Data |
|
Color Index |
Ra>80 , R9>0 |
Power factor |
>0.95 |
|
Beam Angle |
120 degree |
Efficiency in |
>93% |
|
UGR |
<19 |
Energy efficiency Class |
E |
|
Color Temperature |
Tri-Color : 3000/5000K, Mixed: 4000K |
Standard deviation of color matching |
<5 |
|
Dimming Function |
ON/OFF , EM，MS,EM+MS |
Starting Time |
<0.5S |
|
LED current |
Constant 50mA |
Warm-up time to 60% |
<0.5S |
|
Input Voltage |
AC200~240V/50Hz |
Rated nominal Lifetime |
>50,000 hours |
|
Working Voltage |
Constant DC36-42V |
Lumen Maintenance at e.o.l. |
>80% |
|
Housing material |
AL+SPCC |
LED Device Lifetime |
L80/B10@50,000 hours |
|
Temperature |
Operation:-15°C~+50°C ,Storage:-25°C~+55°C |
Switching Cycle before Failure |
>100,000 times |
|
Protection Class |
IP20 |
Color consistency in level |
Max. 6SDCM |
|
Warranty |
5 years |
THD |
<15% |
As one of the most professional vasco ceiling light manufacturers and suppliers in China, we're featured by quality products and competitive price. Please rest assured to buy the newest vasco ceiling light made in China here from our factory. Contact us for customized service.
