Toppo IP65 Photocell Sensor Wall Pack with Philips or Lifud Driver

Construction Features

1、Die-case aluminum housing + PC cover

2、Built-in driver
3、Aluminum PCB for LED heating dissipation
4、LED driver on tray for easy replacement

5、Built-in driver

6、Aluminum PCB for LED heating dissipation

7、LED driver on tray for easy replacement

Technical Features

1、Input Voltage:

Philips driver: AC200-240V 50/60Hz
Toppo driver: AC90-277V

2、Operation Voltage: DC36-42V

3、Total harmonic distortion: THD<15%
4、Power Factor: PF>0.95
5、Color Index: Ra>80
6、Photo cell for smart control

7、Lumen maintenance @6000h:>80%

8、Switching cycle before failure: 100,000
9、IP Rating: IP65
10、Life Span: 50,000 hours
11、Warranty: 5 years
12、Operation Temperature: -15°C~+50°C
13、Storage Temperature: -25°C~+55°C

Philips driver: AC200-240V 50/60Hz
Toppo driver: AC90-277V
14、Operation Voltage: DC36-42V
15、Total harmonic distortion: THD<15%
16、Power Factor: PF>0.95

17.Color Index: Ra>80
18、Photo cell for smart control
19、Lumen maintenance @6000h:>80%

20、Switching cycle before failure: 100,000
21、IP Rating: IP65
22、Life Span: 50,000 hours

23、Warranty: 5 years
24、Operation Temperature: -15°C~+50°C

25、Storage Temperature: -25°C~+55°C
