Patent Aluminum Case LED Tri-proof Light

The Patent Aluminum Case LED Tri-proof Light is suitable for parking, warehouse, swimming pool, kitchen, food factory, tunnel, bridge, sauna and other places where there are special requirements for waterproof, dust proof and anti-corrosion.

Send Inquiry

Product Description

Patent Aluminum Case LED Tri-proof Light uses advanced technology to protect the circuit board from corrosion, water and oxidation. It reduces the working temperature of the power inverter, and protects the circuit from strong isolation, which is safe and reliable for use. It uses advanced energy-saving lamp light source, featuring high luminous efficiency, long life and good light transmission performance. In addition, the Patent Aluminum Case LED Tri-proof Light also sets electronic and mechanical double protection. It automatically cuts off the power after opening the cover, which increases the safety, stability and reliability of use and maintenance.

Applications

The Patent Aluminum Case LED Tri-proof Light can replace fluorescent NCF and is suitable for parking lots, warehouses, swimming pools, kitchens, food factories, tunnels, bridges, saunas, factories and other places with special requirements for waterproof, dustproof, and anti-corrosion, or sports facilities, outdoor and indoor places .

patent aluminum case led tri-proof light

Specifications

· Standard:100LM/W

· Premium:125LM/W

· Deluxe:140LM/W

Product Features

· Owner design clip end cap for easy installation

· 1-10V dimming with flicker free driver

· Compatible Dimmer : Lutron / LEVITON

· Single or Double wiring

· IP 65 /IK10 Approval

· Multiple Link with double wiring

· Patent aluminum case as heatsink

· 5 years warranty

Options

· Single or Double wiring

· Color Index: Ra>80 or Ra>90

· Dimming : 1-10V or ON-OFF

· Lumen Efficacy : 100LM/W , 125LM/W ,140LM/W

patent aluminum case led tri-proof light


Tri-proof : 60cm&120cm
Item	Symbol	L=60cm/2ft			L=120cm/4ft
		Standard	Premium	Deluxe	Standard	Premium	Deluxe
Rated Power	W	22W			40W / 60W
LED Type/Qty	SMD2835	143pcs			234pcs
Lumen Efficacy	LM/W	typ.100	typ.125	typ.140	typ.100	typ.125	typ.140
Luminous Flux	LM	typ.2200	typ.2750	typ.3050	typ.4000/6000	typ.5000/7500	typ.5600/8400
LED Current	mA	Constant 50mA
Color Index	CRI(Ra)	Ra>80, R9>0
Color Temperature	TC(k)	Tri-color : 3000/5000k Mixed : 4000k
Beam Angle	Degree	120 degree
Dimming Function	/	ON-OFF/ 1-10V dimming
Power Factor	PF	PF>0.95
Input Voltage	V	AC200-240V / 50HZ
Housing Material	/	Alumium +PC
Starting Time	S	<0.55
Protection Class	IP	IP65/IK10
Lifespan	h	50,000 hours
Guarantee	/	5 years
Tri-proof : 150cm&240cm
Item	Symbol	L=150cm/5ft			L=240cm / 8ft
		Standard	Premium	Deluxe	Standard	Premium	Deluxe
Rated Power	W	60W			100W
LED Type/Qty	SMD2835	325pcs			520pcs
Lumen Efficacy	LM/W	typ.100	typ.125	typ.140	typ.100	typ.125	typ.140
Luminous Flux	LM	typ.6000	typ.7500	typ.8400	typ.10000	typ.12500	typ.14000
LED Current	mA	Constant 50mA
Color Index	CRI(Ra)	Ra>80, R9>0
Color Temperature	TC(k)	Tri-color : 3000/5000k Mixed : 4000k
Beam Angle	Degree	120 degree
Dimming Function	/	ON-OFF/ 1-10V dimming
Power Factor	PF	PF>0.95
Input Voltage	V	AC200-240V / 50HZ
Housing Material	/	Alumium +PC
Starting Time	S	<0.55
Protection Class	IP	IP65/IK10
Lifespan	h	50,000 hours
Guarantee	/	5 years
