Frosted Batten 1200mm Fixture Easy Installation

Low glare LED batten Fitting 120mm Batten

Product Features

· Paten low glare design on 120mm · Easy open between up-down case · End or rear cable entry · Multiple link without light gap · 5 years warranty

Options

· Tri-color CCT:3000/4000/5000K · Function:ON-OFF / 1-10V dimming · Installation : Surface mounting OR suspension

Application

· Replacement for T8 fluorescent batten · Warehouses,Factories, Car Parks,Supermarkets · Stations,Office · etc

Frosted Kingston Batten
Item	Symbol	L=120cm/4ft		L=150cm/5ft		L=180cm/6ft
Rated Power	W	17W	32W	22W	40W	27W	50W
LED Type / Qty SMD2835	Tri-color	208x2	260x2	260x2	312x2	312x2	364x2
	Single Color	208	260	260	312	312	364
Lumen Efficacy	LM / W	typ. 125
Luminous Flux	LM	2150	4000	2750	5000	3350	6250
UGR	Data	UGR<19
	Condition	Ceiling / 0.7, Wall / 0.5, Working Plan / 0.2
Color Index	CRI(Ra)	Ra>80
Color Temperature	TC(k)	Single color: WWW:3000K , Tri-color : 3000/5000k , Mixed : 4000k
Beam Angle	degree	120 degree
Dimming Function	/	ON-OFF/ 1-10V dimming/ DALI
Power Factor	PF	PF>0.95
Lumen Current	mA	Constant 45mA
Input Voltage	V	AC200-240V / AC100-277V / 50 Hz
Housing Material	/	Aluminum + Pc
Starting Time	S	<0.55
Protection Class	IP	IP20
Lifespan	h	50,000 hours
Guarantee	/	5 years

Company Profile

Under the growing in these years, We not only have the advanced production machines & fixtures, but also We have set up our own engineering laboratory which can do all the safety testing. Such as: the Photometric testing, EMI testing, EMF testing, Surge Testing, ESD testing, IES testing. etc.

“Morality as the basic, quality as the life, customer as the center, innovation as the source, result as the guide”.

FAQ:

1.What’s LGP(PMMA)?

A key component to maximize the uniformity of light, to make the backlight slim and to reorient the line or dot light source such as LED to the plate light source.

2.Are you the factory or trading company ?

Yes sure, we have own factory. We are a worldwide LED manufacturer, which specialize in developing, producing and selling for LED lights.

3.What’s Lumen?

The international (SI) unit of luminous flux or quantity of light and equals the amount of light that is spread over a square foot of surface by one candle power when all parts of the surface are exactly one foot from the light source.

4.How long is the delivery time ?

Samples within 3 working days, bulk order is within 15-20 working days. If you are very

urgent, we will try our best to help you.

5.How to explain “luminous Efficacy“ ?

A measure of how well a light source products visible light expressed as lumens /Watt.
