120DEG SMD2835 Internel Driver LED Single Batten
LED single batten lights are complete LED solutions designed to replace 2ft to 6ft T6 and T8 twins batten fittings in commercial and industrial applications.LED single batten lights are the best replacement for fluorescent twin batten fitting in commercial and industrial applications.
Send Inquiry
  |
|
|
|
|
| Why choose us? |
Toppo Lighting is one of the leading traditional tube fixture led fluorescent replacement? manufacturers and suppliers in China, which is equipped with a productive factory. Welcome to import the newest traditional tube fixture led fluorescent replacement? at competitive price with us. We can also offer you customized service.
|
| Item | Symbol | 2ft/60cm/22w | 4ft/120cm/32w | 5ft/150cm/540W | 5ft/150cm/55W | 6ft/180cm/65W |
| Product Code | / | TP-BTS2D1-22-E0 | TP-BTS4D1-32-E0 | TP-BTS5D1-40-E0 | TP-BTS5D1-55-E0 | TP-BTS6D1-65-E0 |
| Rated Power | W | 18 | 32 | 40 | 55 | 65 |
| LED Typ/Qty | SMD3825 | 132 | 192 | 240 | 364 | 442 |
| Luminous Flux | LM | typ.2650-2850 | typ.3850-4150 | typ.4800-5200 | typ6500-7000 | typ.7800-8400 |
| Luminous Efficacy | LM/W | typ.120-130 | ||||
| Color Index | Ra | Ra>80 | ||||
| Color Temperature | CCT(K) | WW:3000K NW:4000K PW: 5000K CW:6000K | ||||
| Lumen maintance | % | >80% | ||||
| AC Input Voltage | V | AC100-277V | ||||
| Power Factor | PF | PF>0.95 | ||||
| Flicker-free | / | Yes | ||||
| Switching Cycle before Failure | Times | 100000 | ||||
| Life Span | Hours | 50000 hours | ||||
| Warranty | Years | 5 years | ||||
| Operation Temperature | ℃ | -15℃~+50℃ | ||||
| Storage Temperature | ℃ | -25℃~+55℃ | ||||
