1-10 Dimming Surface Mounting LED Batten Light

Low glare LED batten Fitting UL 120mm Batten

Product Features

· Paten low glare design on 120mm · Easy open between up-down case · End or rear cable entry · Multiple link without light gap · 5 years warranty

Options

· Tri-color CCT:3000/4000/5000K · Function:ON-OFF / 1-10V dimming · Installation : Surface mounting OR suspension

Application

· Replacement for T8 fluorescent batten · Warehouses,Factories, Car Parks,Supermarkets · Stations,Office · etc

Frosted Kingston Batten
Item	Symbol	L=120cm/4ft		L=150cm/5ft		L=180cm/6ft
Rated Power	W	17W	32W	22W	40W	27W	50W
LED Type / Qty SMD2835	Tri-color	208x2	260x2	260x2	312x2	312x2	364x2
	Single Color	208	260	260	312	312	364
Lumen Efficacy	LM / W	typ. 125
Luminous Flux	LM	2150	4000	2750	5000	3350	6250
UGR	Data	UGR<19
	Condition	Ceiling / 0.7, Wall / 0.5, Working Plan / 0.2
Color Index	CRI(Ra)	Ra>80
Color Temperature	TC(k)	Single color: WWW:3000K , Tri-color : 3000/5000k , Mixed : 4000k
Beam Angle	degree	120 degree
Dimming Function	/	ON-OFF/ 1-10V dimming/ DALI
Power Factor	PF	PF>0.95
Lumen Current	mA	Constant 45mA
Input Voltage	V	AC200-240V / AC100-277V / 50 Hz
Housing Material	/	Aluminum + Pc
Starting Time	S	<0.55
Protection Class	IP	IP20
Lifespan	h	50,000 hours
Guarantee	/	5 years

Toppo Lighting company limited is one of the professional manufacturer which specialize in developing, producing and selling for Led Lighting. As a worldwide LED manufacturer, We have various series of LED lighting which include: LED Panel Light, LED linear light ,LED tri-proof light , LED batten light ,Led trunk linear ,LED Tube Light, LED Down Light, LED Ceiling Light, LED troffer , etc.

In order to achieve the high quality and capacities, we use the Auto-SMT and Auto production assembly line to meet high quality requirement. By these advance applications. Our monthly production capacity increased, LED panel exceed 60,000 pcs, LED Linear and batten exceed 80,00pcs. The other products exceed 30,000-50,000 pcs for each series.

We always insist our value system “ Morality as the basic , Quality as the life ,Customer as the centre , Innovation as the source , Rseult as the guide ” to make the growing of our team. “Our service your choice ” as the maketing concept to make the best led lighting to emblaze your happy modern life.

FAQ

1. Are you a manufacturer, trading company or a third party?
We are a manufacturer of led commerical and industrial lighting, and we have builded up ourcompany since 2008.

2. Where is your factory located?
Our factory address is : D building of 6th Huangpin Road, Gaoqiao Zone, PinDi Town, LongGan District, Shenzhen, Guangdong Province, China.

3. How can i get to your factory?
Our factory 1.5 hours from Shenzhen Baoan Airport, we can pick you up in the airport or pick you up in anywhere in Shenzhen.

4. If i will need to stay in your place for few days, is that possible to book the hotel for me?
It’s always my pleasure, hotel booking service is available.

5. What is your minimum order quantity, can you send me samples?
Our minimum quantity is 1 set, different led light MOQ is different, usually 100pcs. Samples order always welcome.

6. Which level of quality are your products?
We have got CE, ISO, SGS, TUV, UL, ETL certificate so far.

7. What is the delivery time ?
In general, the delivery time is about 30 days, customized led light will be delivered as the negotiation with our clients.

8.Please feel free to send us your detailed requirements, you would be satisfied with our service.
