Tri-color LED Down Light

Tri-color LED Down Light

Tri-Color LED Down Light Key Features • TRI-Color • Philips Certa driver • SMD2835 as light source • Easy Recessed installation Construction Features • Die-case housing as heatsink • High transmission PC cover • Various of installation clip Application • Replaces traditional halogen • office,...

Send Inquiry

Product Details

Tri-Color LED Down Light


Key Features

• TRI-Color
• Philips Certa driver
• SMD2835 as light source
• Easy Recessed installation



Construction Features

• Die-case housing as heatsink
• High transmission PC cover
• Various of installation clip



Application

• Replaces traditional halogen
• office, meeting room, hall, hotel, super-market, shop etc.



Technical Features

• Input Voltage:
Philips Driver: AC200-240V 50/60Hz
GS Driver: AC200-2240V 50/60Hz
• Operation Voltage: DC36-42V
• Power Factor:
Philips Driver: PF/0.7-0.9
GS driver: PF>0.95
• Lumen maintenance @6000h :>80%
• Switching cycle before failure: 50,000
• IP Rating: IP20
• Life Span: 30,000 hours
• Warranty: 3 years
• Operation Temperature: -15°C~+50°C
• Storage Temperature: -25°C~+55°C



Product Name

Product Code

Rated Power

Input
     Voltage

LED
     Type

LED
     Qty

Power Factor

Luminous Flux (LM)

Lumen Efficacy

(LM/W)

CRI

4"/8W

DLR04-08D

8W

AC90-277V

SMD2835

48*2

PF>0.90

800

100

Ra>80

5"/10W

DLR05-10D

10W

AC90-277V

SMD2835

60*2

PF>0.90

1050

100

Ra>80

6"/15W

DLR06-15D

15W

AC90-277V

SMD2835

72*2

PF>0.95

1500

100

Ra>80

6"/18W

DLR06-18D

18W

AC90-277V

SMD2835

84*2

PF>0.95

1850

100

Ra>80

8"/22W

DLR08-22D

22W

AC90-277V

SMD2835

108*2

PF>0.95

2300

100

Ra>80

8"/30W

DLR08-30D

30W

AC90-277V

SMD2835

156*2

PF>0.95

3150

100

Ra>80




Options

> Led Driver: Philips certa driver or GS AC200-240V driver

> Warm white: WW/3000K

> Neutral white: NW/4000K

> Pure white: PW/5000K

> Cool white: CW/6000K



Toppo Lighting is one of the leading tri-color led down light manufacturers and suppliers in China, which is equipped with a productive factory. Welcome to import the newest tri-color led down light at competitive price with us. We can also offer you customized service.
