Super Thin High Lumen TUV-GS LED Panel


Key Features

• 180 LM/W LM-80 certified SMD4014 as light source
• 110-120 LM/W lighting output
• UGR<19 is available
• Philips Xitanium driver



Construction Features

• Extra thin aluminum frame 10mm
• White or silver paint finish
• Housing material: Aluminum + PMMA + diffuser
• Driver tray is available for easy replacement
• Custom-made size is available
• Recessed / surface monuting / suspension installation



Application

• Replaces fluorescent grid
• Retail, offices, schools, hospitals
• Corridors and stairwells
• Suspended ceiling lighting for offices


Technical Features

• Input Voltage:

AC90-277V 50/60HZ OR AC200-240V 50/60HZ
• Operation Voltage: DC36-42V
• Total harmonic distortion: THD<15%
• Power Factor: PF>0.95
• Color Index: Ra>80
• Lumen maintenance @6000h: >80%
• Switching cycle before failure: 100,000
• IP Rating: IP20
• Life Span: 50,000 hours
• Warranty: 5 years
• Operation Temperature: -15°C~+50°C
• Storage Temperature: -25°C~+55°C


Product Name

Product Code

Rated Power

Input Voltage

LED Type

LED Qty

Power Factor

Luminous Flux(LM)

Lumen Efficacy

CRI

600x600/32W

PL1S22RD1-32

32W

AC200-240V

SMD4014

208

PF>0.95

3600-3800

110-120

Ra>80

600x600/40W

PL1S22RD1-40

40W

AC200-240V

SMD4014

234

PF>0.95

4400-4800

110-120

Ra>80

300x1200/32W

PL1S41RD1-32

32W

AC200-240V

SMD4014

208

PF>0.95

3600-3800

110-120

Ra>80

300x1200/40W

PL1S41RD1-40

40W

AC200-240V

SMD4014

234

PF>0.95

4400-4800

110-120

Ra>80

620x620/40W

PL1S62RD1-40

40W

AC200-240V

SMD4014

234

PF>0.95

4400-4800

110-120

Ra>80

600x1200/60W

PL1S42RD1-60

60W

AC200-240V

SMD4014

312

PF>0.95

6500-7200

110-120

Ra>80

600x1200/72W

PL1S42RD1-72

72W

AC200-240V

SMD4014

364

PF>0.95

8000-8600

110-120

Ra>80


Options

> LED Driver: Philips Xitanium series / GS approved series

> Dimming: STD ON-OFF / 1-10V dimmable

> Emergency: 3 hours integrated emergency

> Warm white: WW/3000K

> Neutral white: NW/4000K

> Pure white: PW/5000K

> Cool white: CW/6000K





Toppo Lighting is one of the leading super thin high lumen tuv-gs led panel manufacturers and suppliers in China, which is equipped with a productive factory. Welcome to import the newest super thin high lumen tuv-gs led panel at competitive price with us. We can also offer you customized service.
